_LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc > Class Template Reference
[Classes and types for internal use]

Labelled directed graph base class for allocator encapsulation. More...

#include <vgtl_ldagbase.h>

Inheritance diagram for _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >:

Inheritance graph

List of all members.

Public Types

typedef _NAlloc node_allocator_type

typedef _EAlloc edge_allocator_type

typedef _Ctr container_type

typedef _Iterator out_iterator

typedef _CIterator out_const_iterator

typedef _Iterator in_iterator

typedef _CIterator in_const_iterator

Public Member Functions

node_allocator_type get_node_allocator () const

edge_allocator_type get_edge_allocator () const

_LDG_base (const node_allocator_type &, const edge_allocator_type &)

~_LDG_base ()

void clear ()

Protected Member Functions

void clear_graph (_LDG_node< _Tp, _Ctr, _Iterator > *_node)

_LDG_node< _Tp, _Ctr, _Iterator > * _C_get_node ()

void _C_put_node (_LDG_node< _Tp, _Ctr, _Iterator > *__p)

_LDG_edge< _Te, _Node > * _C_get_edge ()

void _C_put_edge (_LDG_edge< _Te, _Node > *__p)

void clear_out_edges ()

void clear_in_edges ()

template<class _Output_Iterator >

void add_all_out_edges (_Output_Iterator fi, _LDG_node< _Tp, _Ctr, _Iterator > *_parent)

template<class _Output_Iterator >

void add_all_in_edges (_Output_Iterator fi, _LDG_node< _Tp, _Ctr, _Iterator > *_child)

Protected Attributes

_LDG_node< _Tp, _Ctr, _Iterator > * _C_ground

_LDG_node< _Tp, _Ctr, _Iterator > * _C_sky

int _C_mark

Detailed Description

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>
class _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >

Base directed graph class top level that encapsulates details of allocators. This class is same as _LDG_base and _LDG_alloc_base if STL doesn't support standard allocators.

Definition at line 455 of file vgtl_ldagbase.h.

Member Typedef Documentation

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

typedef _Ctr _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::container_type

internal container used to store the edges

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 468 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

typedef _EAlloc _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::edge_allocator_type

edge allocator type

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 461 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

typedef _CIterator _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::in_const_iterator

const iterator for accessing the out edges

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 476 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

typedef _Iterator _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::in_iterator

iterator for accessing the in edges

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 474 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

typedef _NAlloc _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::node_allocator_type

node allocator type

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 459 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

typedef _CIterator _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::out_const_iterator

const iterator for accessing the out edges

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 472 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

typedef _Iterator _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::out_iterator

iterator for accessing the out edges

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 470 of file vgtl_ldagbase.h.

Constructor & Destructor Documentation

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

_LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_LDG_base	(	const node_allocator_type &	,
		const edge_allocator_type &
	)			`[inline]`

constructor initializing the allocator and the virtual nodes

Definition at line 479 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

_LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::~_LDG_base ( ) [inline]

standard destructor

Definition at line 505 of file vgtl_ldagbase.h.

Member Function Documentation

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

_LDG_edge<_Te,_Node>* _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_C_get_edge ( ) [inline, protected]

allocate a new edge

Definition at line 533 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

_LDG_node<_Tp,_Ctr,_Iterator>* _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_C_get_node ( ) [inline, protected]

allocate a new node

Definition at line 526 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_C_put_edge ( _LDG_edge< _Te, _Node > * __p ) [inline, protected]

deallocate a edge

Definition at line 536 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_C_put_node ( _LDG_node< _Tp, _Ctr, _Iterator > * __p ) [inline, protected]

deallocate a node

Definition at line 529 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

template<class _Output_Iterator >

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::add_all_in_edges	(	_Output_Iterator	fi,
		_LDG_node< _Tp, _Ctr, _Iterator > *	_child
	)			`[inline, protected]`

add all in edges to the child _child. fi is a iterator to the in edges container of the child

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

template<class _Output_Iterator >

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::add_all_out_edges	(	_Output_Iterator	fi,
		_LDG_node< _Tp, _Ctr, _Iterator > *	_parent
	)			`[inline, protected]`

add all out edges to the parent _parent. fi is a iterator to the out edges container of the parent

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::clear ( )

empty the graph

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, ldgraph< _Tp, _SequenceCtr, _PtrAlloc, _Alloc >, __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >, and ldgraph< _Tp, _SequenceCtr, _PtrAlloc, _Alloc >.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::clear_graph ( _LDG_node< _Tp, _Ctr, _Iterator > * _node ) [protected]

removes recursively all nodes and edges downward starting from _node.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::clear_in_edges ( ) [inline, protected]

clear all in edges of the sky node

Definition at line 551 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

void _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::clear_out_edges ( ) [inline, protected]

clear all out edges of the ground node

Definition at line 548 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

edge_allocator_type _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::get_edge_allocator ( ) const [inline]

get an edge allocator object

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 465 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

node_allocator_type _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::get_node_allocator ( ) const [inline]

get a node allocator object

Reimplemented in __LDG< _Tp, _Te, _Ctr, _Iterator, _CIterator, _Inserter, _NAlloc, _EAlloc >, and __LDG< _Tp, _SequenceCtr< void *, _PtrAlloc >, _SequenceCtr< void *, _PtrAlloc >::iterator, _SequenceCtr< void *, _PtrAlloc >::const_iterator, _SequenceCtr< void *, _PtrAlloc >::iterator, _Alloc >.

Definition at line 463 of file vgtl_ldagbase.h.

Member Data Documentation

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

_LDG_node<_Tp,_Ctr,_Iterator>* _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_C_ground [protected]

the virtual ground node (below all roots)

Definition at line 541 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

int _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_C_mark [protected]

an internal counter for setting marks during certain algorithms

Definition at line 545 of file vgtl_ldagbase.h.

template<class _Tp, class _Ctr, class _Iterator, class _CIterator, class _Te, class _NAlloc, class _EAlloc>

_LDG_node<_Tp,_Ctr,_Iterator>* _LDG_base< _Tp, _Ctr, _Iterator, _CIterator, _Te, _NAlloc, _EAlloc >::_C_sky [protected]

the virtual sky node (above all leafs)

Definition at line 543 of file vgtl_ldagbase.h.

The documentation for this class was generated from the following file:

vgtl_ldagbase.h
